ELITE SQUARE MOTOR

ROLLER BLIND WITH BOX C80/C100



MVS80M
MVS100M

Box made of extruded aluminium 6060, powder-coated in white RAL 9010/painted silver/matt black
RAL 9005, consisting of a fixed part and a movable part.
46/53 mm diameter winding tubes made of extruded aluminium alloy 6063, all equipped with an
ogive to facilitate fabric maintenance and internal grooves to prevent bending.
End closing plates in white, grey and black.

Bottom rail made of extruded aluminium alloy 6060, with rectangular section as standard: dimensions 18×24 mm, powder-coated white RAL 9010/painted silver/matt black RAL 9005.
Bottom rail plastic end closing caps in white/black/grey.
Radio or button control.
Motor (230 V/50 Hz) with adjustable electronic limit switch.

TYPES AND CHARACTERISTICS

RAL

   White

   Black

   Painted silver

MVS80M

MVS100M

STANDARD        ON REQUEST

HOW TO ORDER – EXTRA CHARGES

  • Surcharge for super silent motor (51/53 dB) with mechanical limit switch € 50.00
  • Extra charge for motor system with radio receiver (excl. radio control) € 186.00
  • 1-channel remote control € 60.00
  • 15-channel remote control € 115.00

DOWNLOAD

This content has been restricted to logged in users only. Please login to view this content.
